Zyxel GS1900-8HP v3 PoE. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8. Full duplex. MAC address table: 8 entries, Switching capacity: 16 Gbit/s. Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE.... Power connector: DC-in jack. Power over Ethernet (PoE)
| Management features |
| Switch type |
Managed |
| Switch layer |
L2 |
| Quality of Service (QoS) support |
Y |
| Web-based management |
Y |
| Ports & interfaces |
| Basic switching RJ-45 Ethernet ports quantity |
8 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Power connector |
DC-in jack |
| Network |
| Networking standards |
IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
| Full duplex |
Y |
| Flow control support |
Y |
| Broadcast storm control |
Y |
| Rate limiting |
Y |
| Auto MDI/MDI-X |
Y |
| VLAN support |
Y |
| Data transmission |
| Switching capacity |
16 Gbit/s |
| MAC address table |
8 entries |
| Number of queues |
8 |
| Jumbo frames support |
Y |
| Jumbo frames |
9216 |
| Security |
| DHCP features |
DHCP client |
| IGMP snooping |
Y |
| Security algorithms |
802.1x RADIUS |
| MAC address filtering |
Y |
| Multicast features |
| Multicast support |
Y |
| Design |
| Product colour |
Black |
| Reset button |
Y |
| Certification |
CE, FCC, C-Tick, RoHS |
| Performance |
| Mean time between failures (MTBF) |
533086 h |
| Power |
| Power source |
DC |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Power consumption (typical) |
90 W |
| Power over Ethernet (PoE) |
| Power over Ethernet (PoE) |
Y |
| Power over Ethernet (PoE) ports quantity |
8 |
| Total Power over Ethernet (PoE) budget |
70 W |
| Operational conditions |
| Operating relative humidity (H-H) |
10 - 90% |
| Weight & dimensions |
| Width |
250 mm |
| Depth |
104 mm |
| Height |
27 mm |
| Weight |
710 g |
| Logistics data |
| Harmonized System (HS) code |
85176990 |
