| Management features |
| Switch type |
Managed |
| Switch layer |
L2 |
| Quality of Service (QoS) support |
Y |
| Web-based management |
Y |
| ARP inspection |
Y |
| System event log |
Y |
| MIB support |
RFC 2233 IF MIB, RFC1213 MIB II, RFC 1757 RMON 1/2/3/9, RFC1215, RFC1493, RFC 2674, LLDP-EXT-MED MIB |
| Ports & interfaces |
| Basic switching RJ-45 Ethernet ports quantity |
8 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| SFP module slots quantity |
4 |
| Fiber optic connector |
SFP |
| Network |
| Networking standards |
IEEE 802.1D,IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3at,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z |
| 10G support |
N |
| Copper ethernet cabling technology |
10BASE-T,100BASE-TX,1000BASE-T |
| Port mirroring |
Y |
| Full duplex |
Y |
| Flow control support |
Y |
| Link aggregation |
Y |
| Broadcast storm control |
Y |
| Rate limiting |
Y |
| Auto-negotiation |
Y |
| VLAN support |
Y |
| Virtual LAN features |
Tagged VLAN |
| Number of VLANs |
1024 |
| Optical fiber |
| Fiber ethernet cabling technology |
1000BASE-X |
| Transmission distance (max) |
40 km |
| Data transmission |
| Switching capacity |
24 Gbit/s |
| Throughput |
17.86 Mpps |
| MAC address table |
8000 entries |
| Store-and-forward |
Y |
| Number of queues |
8 |
| Jumbo frames support |
Y |
| Jumbo frames |
9000 |
| Packet buffer memory |
0.5 MB |
| Security |
| Access Control List (ACL) |
Y |
| IGMP snooping |
Y |
| Security algorithms |
802.1x RADIUS,HTTPS,SNMP,SSH-2 |
| MAC address filtering |
Y |
| SSH/SSL support |
Y |
| Authentication |
Guest VLAN, MAC-based authentication, Port-based authentication |
| Multicast features |
| Multicast support |
Y |
| Design |
| Rack mounting |
Y |
| Product colour |
Black |
| Housing material |
Metal |
| International Protection (IP) code |
IP30 |
| Wall mountable |
Y |
| DIN rail mounting |
Y |
| Performance |
| Firmware upgradeable |
Y |
| Buffer size |
512 KB |
| Plug and Play |
Y |
| Mean time between failures (MTBF) |
568430 h |
| Power |
| DC input voltage |
12 - 58 V |
| Power consumption (max) |
255 W |
| Power over Ethernet (PoE) |
| Power over Ethernet (PoE) |
Y |
| Power over Ethernet plus (PoE+) ports quantity |
8 |
| Total Power over Ethernet (PoE) budget |
240 W |
| Operational conditions |
| Operating temperature (T-T) |
-40 - 75 °C |
| Storage temperature (T-T) |
-40 - 85 °C |
| Operating relative humidity (H-H) |
5 - 95% |
| Storage relative humidity (H-H) |
5 - 90% |
| Heat dissipation |
86955 BTU/h |
| Weight & dimensions |
| Width |
77 mm |
| Depth |
127.3 mm |
| Height |
154 mm |
| Weight |
1.45 kg |
| Packaging data |
| Wall mounting kit |
Y |
| Rack mount kit |
Y |
| Package width |
133 mm |
| Package depth |
192 mm |
| Package height |
238 mm |
| Package weight |
1.9 kg |
| Other features |
| Input voltage |
12 - 58 V |
