TP-LINK TL-MR3020. Wi-Fi band: Single-band (2.4 GHz), Top Wi-Fi standard: Wi-Fi 4 (802.11n), WLAN data transfer rate (max): 300 Mbit/s. Ethernet LAN interface type: Fast Ethernet, Ethernet LAN data rates: 10,100 Mbit/s, Networking standards: IEEE 802.11b,IEEE 802.11g,IEEE 802.11n. Mobile network generation: 4G. Security algorithms: 64-bit WEP,128-bit WEP,WPA-PSK,WPA2-PSK, Firewall security: DoS, SPI. Product type: Tabletop router
| WAN connection |
| Ethernet WAN |
Y |
| DSL WAN |
N |
| SIM card slot |
N |
| 3G/4G USB modem compatibility |
Y |
| Wireless LAN features |
| Wi-Fi band |
Single-band (2.4 GHz) |
| Top Wi-Fi standard |
Wi-Fi 4 (802.11n) |
| WLAN data transfer rate (max) |
300 Mbit/s |
| Wi-Fi standards |
802.11b,802.11g,Wi-Fi 4 (802.11n) |
| Network |
| Ethernet LAN |
Y |
| Ethernet LAN interface type |
Fast Ethernet |
| Ethernet LAN data rates |
10,100 Mbit/s |
| Networking standards |
IEEE 802.11b,IEEE 802.11g,IEEE 802.11n |
| Port forwarding |
Y |
| Port triggering |
Y |
| Dynamic DNS (DDNS) |
Y |
| Receiver sensitivity |
270M: -70dBm@10% PER
130M: -73dBm@10% PER
108M: -74dBm@10% PER
54M: -75dBm@10% PER
11M: -86dBm@8% PER
6M: -92dBm@10% PER
1M: -95dBm@8% PER |
| Mobile network |
| 3G |
Y |
| Mobile network generation |
4G |
| 4G |
N |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports |
1 |
| USB port |
Y |
| USB 2.0 ports quantity |
1 |
| Memory card slot(s) |
N |
| Management features |
| Web-based management |
Y |
| Wi-Fi Multimedia (WMM)/(WME) |
Y |
| Quality of Service (QoS) support |
Y |
| Reset button |
Y |
| WPS push button |
Y |
| Security |
| Security algorithms |
64-bit WEP,128-bit WEP,WPA-PSK,WPA2-PSK |
| Firewall |
Y |
| Firewall security |
DoS, SPI |
| Guest access |
Y |
| DoS attack prevention |
Y |
| Parental control |
Y |
| MAC address filtering |
Y |
| DMZ support |
Y |
| Protocols |
| DHCP client |
Y |
| DHCP server |
Y |
| Universal Plug and Play (UPnP) |
Y |
| Design |
| Product type |
Tabletop router |
| Antenna |
| Antenna type |
Internal |
| Transmit power |
20 dBmW |
| Features |
| Certification |
CE, FCC, RoHS |
| Power |
| Power source type |
DC |
| Output voltage |
5 V |
| Output current |
1 A |
| Operational conditions |
| Operating temperature (T-T) |
-10 - 60 °C |
| Storage temperature (T-T) |
-40 - 80 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
5 - 90% |
| System requirements |
| Windows operating systems supported |
Windows 10,Windows 2000,Windows 7,Windows 98SE,Windows NT,Windows Vista,Windows XP |
| Linux operating systems supported |
Y |
| Mac operating systems supported |
Y |
| Weight & dimensions |
| Width |
74 mm |
| Depth |
67 mm |
| Height |
22 mm |
| Packaging data |
| Cables included |
LAN (RJ-45), USB |
| Quick installation guide |
Y |
