| Storage |
| Supported storage drive interfaces |
Serial ATA II, Serial ATA III |
| Storage drive sizes supported |
2.5,3.5" |
| RAID support |
Y |
| RAID levels |
0, 1, 5, 6, 10, JBOD |
| Online RAID migration |
Y |
| Online RAID expansion |
Y |
| RAID rebuild |
Y |
| Hot-swap drive bays |
Y |
| Supported file systems |
FAT32, HFS+, NTFS, exFAT, ext3, ext4 |
| Storage drives installed |
N |
| Number of storage drives supported |
4 |
| Installed storage drive type |
N |
| Supported storage drive types |
HDD & SSD |
| Disk roaming |
Y |
| Processor |
| Processor manufacturer |
Intel |
| Processor family |
Intel® Celeron® |
| Processor boost frequency |
2.9 GHz |
| Processor cores |
4 |
| Processor threads |
4 |
| On-board graphics card model |
Intel® UHD Graphics |
| Memory |
| Maximum RAM supported |
16 GB |
| Internal memory |
8 GB |
| Flash memory |
4000 MB |
| Network |
| Ethernet LAN |
Y |
| Ethernet LAN data rates |
10,100,1000,2500 Mbit/s |
| DHCP client |
Y |
| DHCP server |
Y |
| Jumbo frames support |
Y |
| iSCSI support |
Y |
| Wake-on-LAN ready |
Y |
| Dynamic DNS (DDNS) |
Y |
| Ports & interfaces |
| USB port |
Y |
| USB 2.0 ports quantity |
2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
2 |
| HDMI ports quantity |
1 |
| HDMI version |
1.4b |
| Ethernet LAN (RJ-45) ports |
2 |
| PCI Express x2 (Gen 3.x) slots |
1 |
| Design |
| Chassis type |
Rack (1U) |
| Cooling type |
Active |
| Product colour |
Black |
| Number of fans |
2 fan(s) |
| Fan diameter |
4 cm |
| LED indicators |
HDD, LAN, Power, Status |
| Performance |
| Type |
NAS |
| Device class |
Small & Medium Business |
| Backup function |
Y |
| Backup features |
Cloud, iSCSI LUN |
| Buzzer |
Y |
| Multilingual support |
Y |
| Snapshot |
Y |
| Security algorithms |
256-bit AES, FIPS 140-2, HTTPS, SSH |
| Access Control List (ACL) |
Y |
| Reset button |
Y |
| On/off switch |
Y |
| Built-in FTP server |
Y |
| Browser supported |
Apple Safari, Google Chrome, Microsoft Edge, Mozilla Firefox |
| System log |
Y |
| Hot spare |
Y |
| Disk scan |
Y |
| S.M.A.R.T. support |
Y |
| Share folder |
CIFS/SMB |
| Software |
| Operating system installed |
QNAP Turbo System |
| Operating system version |
5.0.1 |
| Windows operating systems supported |
Windows 10, Windows 11, Windows 7, Windows 8 |
| Linux operating systems supported |
Y |
| Mac operating systems supported |
Y |
| Server operating systems supported |
Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Power |
| Power supply location |
Built-in |
| Power supply unit (PSU) capacity |
250 W |
| Number of power supply units |
1 |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Fan voltage |
12 V |
| Weight & dimensions |
| Width |
430 mm |
| Depth |
479 mm |
| Height |
43.3 mm |
| Weight |
6.6 kg |
| Package weight |
8.54 kg |
| Packaging content |
| Cables included |
AC, LAN (RJ-45) |
| Power cables quantity |
1 |
| Number of screws |
84 |
| Technical details |
| Harmonized System (HS) code |
84714100 |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
5 - 95% |
| Storage temperature (T-T) |
-20 - 70 °C |
