| Storage |
| Supported storage drive interfaces |
Serial ATA II, Serial ATA III |
| Storage drive sizes supported |
2.5,3.5" |
| RAID support |
Y |
| RAID levels |
0,1,5,6,10,JBOD |
| Online RAID migration |
Y |
| Online RAID expansion |
Y |
| RAID rebuild |
Y |
| Hot-swap drive bays |
Y |
| Supported file systems |
FAT32,HFS+,NTFS,ext3,ext4 |
| Storage drives installed |
N |
| Number of storage drives supported |
8 |
| Installed storage drive type |
N |
| Supported storage drive types |
HDD & SSD |
| Bad block scan |
Y |
| Processor |
| Processor manufacturer |
Annapurna Labs |
| Processor family |
Annapurna Labs |
| Processor model |
AL324 |
| Processor frequency |
1.7 GHz |
| Processor cores |
4 |
| Memory |
| Internal memory type |
DDR4 |
| Maximum RAM supported |
16 GB |
| Memory slots |
1 |
| Internal memory |
4 GB |
| Memory form factor |
UDIMM |
| Flash memory |
512 MB |
| Network |
| Ethernet LAN |
Y |
| Ethernet LAN data rates |
100,1000,2500,10000 Mbit/s |
| Ethernet LAN data rate supported (max) |
10000 Mbit/s |
| DHCP client |
Y |
| DHCP server |
Y |
| Jumbo frames support |
Y |
| iSCSI support |
Y |
| Wake-on-LAN ready |
Y |
| Supported network protocols |
PPTP, L2TP/IPSec, OpenVPN, QBelt |
| Link aggregation |
Y |
| Load balancing system |
Y |
| WLAN adapter supported |
Y |
| Ports & interfaces |
| USB port |
Y |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
4 |
| Fiber ports quantity |
2 |
| Fiber optic connector |
SFP+ |
| Ethernet LAN (RJ-45) ports |
2 |
| Design |
| Chassis type |
Rack (2U) |
| Cooling type |
Active |
| Product colour |
Black |
| Number of fans |
2 fan(s) |
| Fan diameter |
7 cm |
| LED indicators |
HDD, LAN, Status |
| Performance |
| Type |
NAS |
| Device class |
Small & Medium Business |
| Backup function |
Y |
| Backup features |
Cloud, iSCSI LUN |
| Buzzer |
Y |
| Multilingual support |
Y |
| Noise level |
30.6 dB |
| Snapshot |
Y |
| Web-based management |
Y |
| Security algorithms |
256-bit AES,FIPS 140-2,HTTPS,SSH,SSL/TLS |
| Access Control List (ACL) |
Y |
| Reset button |
Y |
| On/off switch |
Y |
| Built-in FTP server |
Y |
| Browser supported |
Mozilla Firefox, Microsoft Internet Explorer 10+, Apple Safari 7+, Google Chrome |
| System log |
Y |
| Hot spare |
Y |
| S.M.A.R.T. support |
Y |
| Share folder |
CIFS/SMB |
| Universal Plug and Play (UPnP) |
Y |
| USB copy function |
Y |
| Software |
| Operating system installed |
QNAP Turbo System |
| Operating system version |
4.4.3 |
| Windows operating systems supported |
Windows 10,Windows 7,Windows 8 |
| Linux operating systems supported |
Y |
| Mac operating systems supported |
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina |
| Server operating systems supported |
Windows Server 2008 R2,Windows Server 2012,Windows Server 2012 R2,Windows Server 2016,Windows Server 2019 |
| Power |
| Power supply location |
Built-in |
| Power supply unit (PSU) capacity |
250 W |
| Number of power supply units |
2 |
| Power consumption (typical) |
69.191 W |
| AC input voltage |
100 - 240 V |
| Fan voltage |
12 V |
| Weight & dimensions |
| Width |
482 mm |
| Depth |
534 mm |
| Height |
89 mm |
| Weight |
10.9 kg |
| Package weight |
16.9 kg |
| Packaging content |
| Cables included |
AC, LAN (RJ-45) |
| Number of screws |
56 |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
5 - 95% |
