| Storage |
| Storage drive interface |
Serial ATA II, Serial ATA III |
| Supported storage drive interfaces |
Serial ATA II, Serial ATA III |
| Storage drive size |
2.5/3.5" |
| Storage drive sizes supported |
2.5,3.5" |
| RAID support |
Y |
| RAID levels |
0,1,5,6,10,50,60,JBOD |
| Hot-swap drive bays |
Y |
| Storage drives installed |
N |
| Number of storage drives supported |
12 |
| Installed storage drive type |
N |
| Supported storage drive types |
HDD & SSD |
| Processor |
| Processor manufacturer |
AMD |
| Processor family |
Ryzen Embedded |
| Processor model |
V1500B |
| Processor frequency |
2.2 GHz |
| Processor cores |
4 |
| Processor threads |
8 |
| L2 cache |
2 MB |
| L3 cache |
4 MB |
| Memory |
| Internal memory type |
DDR4 |
| Maximum RAM supported |
32 GB |
| Memory slots |
2 |
| Internal memory |
8 GB |
| Memory form factor |
DIMM |
| Flash memory |
5000 MB |
| Network |
| Ethernet LAN |
Y |
| Ethernet LAN data rates |
10,100,1000,2500 Mbit/s |
| DHCP client |
Y |
| DHCP server |
Y |
| Jumbo frames support |
Y |
| Dynamic DNS (DDNS) |
Y |
| Ports & interfaces |
| USB port |
Y |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
2 |
| Ethernet LAN (RJ-45) ports |
2 |
| Design |
| Chassis type |
Rack (2U) |
| Cooling type |
Active |
| Product colour |
Black, Grey |
| Number of fans |
2 fan(s) |
| Fan diameter |
8 cm |
| Fan diameter 2 |
8 cm |
| LED indicators |
HDD, LAN, Power, Status, USB |
| Performance |
| Type |
NAS |
| Device class |
Small & Medium Business |
| Backup function |
Y |
| Backup features |
Cloud, iSCSI LUN |
| Multilingual support |
Y |
| Software |
| Operating system installed |
QNAP Turbo System |
| Operating system version |
4.4.2 |
| Windows operating systems supported |
Windows 10,Windows 7,Windows 8 |
| Linux operating systems supported |
Y |
| Mac operating systems supported |
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina |
| Server operating systems supported |
Windows Server 2008 R2,Windows Server 2008 R2 x64,Windows Server 2012,Windows Server 2012 R2,Windows Server 2012 R2 x64,Windows Server 2012 x64,Windows Server 2016,Windows Server 2016 x64,Windows Server 2019 |
| Other operating systems supported |
Solaris 10 |
| Power |
| Power supply location |
Built-in |
| Power supply unit (PSU) capacity |
300 W |
| Number of power supply units |
2 |
| Power consumption (typical) |
78.92 W |
| Power consumption (sleep) |
43.67 W |
| AC input voltage |
100 - 240 V |
| Weight & dimensions |
| Width |
482 mm |
| Depth |
425 mm |
| Height |
89 mm |
| Weight |
9.69 kg |
| Package weight |
14.6 kg |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
5 - 95% |
