QNAP QSW-M408S. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8, Console port: RJ-45. Full duplex. MAC address table: 16000 entries, Switching capacity: 96 Gbit/s. Networking standards: IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1p,IEEE 802.1w,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE...
| Management features |
| Switch type |
Managed |
| Switch layer |
L2 |
| Quality of Service (QoS) support |
Y |
| Web-based management |
Y |
| Ports & interfaces |
| Basic switching RJ-45 Ethernet ports quantity |
8 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Fiber ports quantity |
4 |
| Fiber optic connector |
SFP+ |
| Console port |
RJ-45 |
| Network |
| Networking standards |
IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1p,IEEE 802.1w,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3ae,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z |
| Copper ethernet cabling technology |
10BASE-T,10GBASE-T,1000BASE-LX,1000BASE-SX,1000BASE-T |
| Cable types supported |
Cat5,Cat5e,Cat6 |
| Full duplex |
Y |
| Flow control support |
Y |
| Spanning tree protocol |
Y |
| Auto-negotiation |
Y |
| VLAN support |
Y |
| Virtual LAN features |
Port-based VLAN,Private VLAN |
| Data transmission |
| Switching capacity |
96 Gbit/s |
| MAC address table |
16000 entries |
| Jumbo frames support |
Y |
| Jumbo frames |
9000 |
| Security |
| DHCP features |
DHCP client |
| Access Control List (ACL) |
Y |
| IGMP snooping |
Y |
| Design |
| Rack mounting |
N |
| Stackable |
N |
| Product colour |
White |
| Reset button |
Y |
| LED indicators |
Activity, Link, Power, Speed, Status |
| Certification |
CE, FCC, VCCI, BSMI |
| Power |
| Power supply included |
Y |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Power consumption (max) |
12.17 W |
| Power over Ethernet (PoE) |
| Power over Ethernet (PoE) |
N |
| Operational conditions |
| Operating temperature (T-T) |
0 - 45 °C |
| Operating relative humidity (H-H) |
5 - 95% |
| Weight & dimensions |
| Width |
290 mm |
| Depth |
127 mm |
| Height |
42.5 mm |
| Weight |
1.15 kg |
| Packaging data |
| Cables included |
AC |
| Quick start guide |
Y |
| Package weight |
1.56 kg |
| .N.B.: Questa scheda è da ritenersi puramente informativa e non contiene alcun tipo di garanzia né implicita né esplicita.. |
