| Management features |
| Switch type |
Managed |
| Switch layer |
L2/L3/L4 |
| Quality of Service (QoS) support |
Y |
| Web-based management |
Y |
| ARP inspection |
Y |
| Ports & interfaces |
| Basic switching RJ-45 Ethernet ports quantity |
8 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| SFP module slots quantity |
2 |
| Network |
| Networking standards |
IEEE 802.3ab,IEEE 802.3af,IEEE 802.3i,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z |
| Copper ethernet cabling technology |
10BASE-T,100BASE-TX,1000BASE-T |
| Port mirroring |
Y |
| Full duplex |
Y |
| Flow control support |
Y |
| Link aggregation |
Y |
| Broadcast storm control |
Y |
| Rate limiting |
Y |
| Spanning tree protocol |
Y |
| MAC address auto-learning supported |
Y |
| Number of VLANs |
64 |
| Data transmission |
| Switching capacity |
20 Gbit/s |
| MAC address table |
8000 entries |
| Store-and-forward |
Y |
| Jumbo frames support |
Y |
| Packet buffer memory |
0.5 MB |
| Security |
| DHCP features |
DHCP client |
| Access Control List (ACL) |
Y |
| Access Control List (ACL) IPv6 entries |
100 |
| IGMP snooping |
Y |
| Security algorithms |
802.1x RADIUS |
| MAC address filtering |
Y |
| Multicast features |
| Multicast support |
Y |
| IPv4 multicast entries |
32 |
| Number of multicast groups filtered |
256 |
| Protocols |
| Management protocols |
SNMP |
| Switching protocols |
SNMP |
| Data link protocols |
Ethernet, Fast Ethernet, Gigabit Ethernet |
| Supported network protocols |
HTTP, HTTPS |
| Design |
| Product colour |
Grey |
| LED indicators |
Activity, LAN, Link, PoE, Power, Speed |
| Certification |
CE, FCC, VCCI Class B, C-Tick |
| Performance |
| Processor frequency |
500 MHz |
| Memory type |
RAM |
| Internal memory |
128 MB |
| Flash memory |
32 MB |
| Mean time between failures (MTBF) |
1200041 h |
| Power |
| Power supply included |
Y |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| DC input voltage |
54 V |
| Input current |
1.25 A |
| Power consumption (max) |
15.1 W |
| Power over Ethernet (PoE) |
| Power over Ethernet (PoE) |
Y |
| Power over Ethernet plus (PoE+) ports quantity |
8 |
| Power over Ethernet (PoE) power per port |
55 W |
| Total Power over Ethernet (PoE) budget |
69.5 W |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 70 °C |
| Operating relative humidity (H-H) |
0 - 95% |
| Storage relative humidity (H-H) |
0 - 95% |
| Operating altitude |
0 - 3000 m |
| Non-operating altitude |
0 - 3000 m |
| Heat dissipation |
237.38 BTU/h |
| Weight & dimensions |
| Width |
236 mm |
| Depth |
101 mm |
| Height |
27 mm |
| Weight |
610 g |
| Packaging data |
| Manual |
Y |
| Package type |
Box |
| Package width |
161 mm |
| Package depth |
267 mm |
| Package height |
86 mm |
| Package weight |
1.49 kg |
| Logistics data |
| Master (outer) case width |
27.4 cm |
| Master (outer) case length |
35 cm |
| Master (outer) case height |
30.9 cm |
| Master (outer) case gross weight |
9.73 kg |
| Products per master (outer) case |
6 pc(s) |
