| Management features |
| Switch type |
Managed |
| Switch layer |
L2 |
| Quality of Service (QoS) support |
Y |
| Web-based management |
Y |
| Ports & interfaces |
| Basic switching RJ-45 Ethernet ports quantity |
8 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity |
8 |
| SFP module slots quantity |
2 |
| Power connector |
DC-in jack |
| Network |
| Networking standards |
IEEE 802.3,IEEE 802.3ab,IEEE 802.3u,IEEE 802.3x |
| 10G support |
N |
| Copper ethernet cabling technology |
10BASE-T,100BASE-T,1000BASE-T |
| Cable types supported |
Cat5,Cat5e |
| Port mirroring |
Y |
| Full duplex |
Y |
| Flow control support |
Y |
| Link aggregation |
Y |
| Auto MDI/MDI-X |
Y |
| Data transmission |
| Switching capacity |
20 Gbit/s |
| Forwarding rate |
14.88 Mpps |
| MAC address table |
8000 entries |
| Store-and-forward |
Y |
| Packet buffer memory |
0.512 MB |
| Security |
| Access Control List (ACL) |
Y |
| MAC address filtering |
Y |
| Multicast features |
| Multicast support |
Y |
| Design |
| Rack mounting |
Y |
| Stackable |
Y |
| Form factor |
1U |
| Product colour |
Black |
| LED indicators |
Y |
| Certification |
EMI: CE Class A, VCCI Class A, FCC Class A, BSMI, CCC |
| Performance |
| Mean time between failures (MTBF) |
729258 h |
| Technical details |
| Shipping (inner) case height |
31.7 cm |
| Shipping (inner) case width |
34.6 cm |
| Shipping (inner) case length |
38.2 cm |
| Shipping (inner) case net weight |
11.1 kg |
| Products per shipping (inner) case |
5 pc(s) |
| Pallet gross weight (air) |
449.5 kg |
| Master (outer) cases per pallet (air) |
36 pc(s) |
| Products per pallet (air) |
180 pc(s) |
| Pallet gross length |
110 cm |
| Pallet gross width |
120 cm |
| Pallet height (air) |
140.3 cm |
| Pallet gross weight (sea) |
662 kg |
| Master (outer) cases per pallet (sea) |
54 pc(s) |
| Products per pallet (sea) |
270 pc(s) |
| Pallet height (sea) |
2.04 m |
| Shipping (inner) case gross weight |
11.8 kg |
| Power |
| Power consumption (max) |
80.6 W |
| Power over Ethernet (PoE) |
| Power over Ethernet (PoE) |
Y |
| Total Power over Ethernet (PoE) budget |
65 W |
| Operational conditions |
| Operating temperature (T-T) |
-5 - 50 °C |
| Storage temperature (T-T) |
-20 - 70 °C |
| Operating relative humidity (H-H) |
0 - 95% |
| Storage relative humidity (H-H) |
0 - 95% |
| Heat dissipation |
373.96 BTU/h |
| Weight & dimensions |
| Width |
280 mm |
| Depth |
126 mm |
| Height |
44 mm |
| Weight |
950 g |
| Packaging data |
| Package width |
288 mm |
| Package depth |
331 mm |
| Package height |
72 mm |
| Package weight |
2.21 kg |
| .N.B.: Questa scheda è da ritenersi puramente informativa e non contiene alcun tipo di garanzia né implicita né esplicita.. |
