| Features |
| 2.4 GHz |
Y |
| 5 GHz |
Y |
| Maximum data transfer rate |
3600 Mbit/s |
| Maximum data transfer rate (2.4 GHz) |
1147 Mbit/s |
| Maximum data transfer rate (5 GHz) |
2402 Mbit/s |
| Ethernet LAN data rates |
10,100,1000,2500 Mbit/s |
| Frequency band |
2.4 - 2.483, 5.15 - 5.35, 5.47 - 5.85 GHz |
| Networking standards |
IEEE 802.11a,IEEE 802.11ac,IEEE 802.11ax,IEEE 802.11b,IEEE 802.11e,IEEE 802.11g,IEEE 802.11n,IEEE 802.3,IEEE 802.3ab,IEEE 802.3af,IEEE 802.3at,IEEE 802.3az,IEEE 802.3u |
| Automatic channel selection |
Y |
| MIMO |
Y |
| MIMO type |
Multi User MIMO |
| Wi-Fi Multimedia (WMM)/(WME) |
Y |
| Wi-Fi roaming |
Y |
| Wireless isolation |
Y |
| Mean time between failures (MTBF) |
30000 h |
| Security |
| Security algorithms |
64-bit WEP,128-bit WEP,SSH,SSL/TLS,WPA,WPA-Enterprise,WPA-PSK,WPA2,WPA2-Enterprise,WPA3,WPA3-Enterprise,WPA3-PSK |
| MAC address filtering |
Y |
| Service Set Identifier (SSID) features |
SSID broadcast, SSID broadcast on/off |
| Number of SSID supported |
16 |
| IGMP snooping |
Y |
| Auto Wireless Distribution System (WDS) |
Y |
| Remote Authentication Dial-In User Service (RADIUS) |
Y |
| Protocols |
| DHCP server |
Y |
| Management protocols |
SNMP (v1, v2c, v3), Telnet, SSH, SSL |
| Management features |
| Web-based management |
Y |
| Command-line interface (CLI) |
Y |
| Syslog |
Y |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports |
3 |
| DC-in jack |
Y |
| Power |
| Power over Ethernet (PoE) |
Y |
| Output voltage |
12 V |
| Output current |
2.5 A |
| Power consumption (max) |
19.44 W |
| Design |
| Placement |
Ceiling, Wall |
| Product colour |
White |
| Housing material |
Plastic |
| Reset button |
Y |
| LED indicators |
Power, Status |
| Certification |
FCC |
| Antenna |
| Antenna type |
Internal |
| Antenna direction type |
Omni-directional |
| Antennas quantity |
4 |
| Antenna gain level (max) |
5.5 dBi |
| Operational conditions |
| Operating relative humidity (H-H) |
10 - 90% |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 65 °C |
| Storage relative humidity (H-H) |
5 - 95% |
| Technical details |
| Sustainability compliance |
Y |
| Sustainability certificates |
CE |
| Weight & dimensions |
| Width |
212.4 mm |
| Depth |
212.4 mm |
| Height |
46.7 mm |
| Weight |
763.8 g |
| Packaging data |
| Number of products included |
1 pc(s) |
