| Management features |
| Switch type |
Managed |
| Switch layer |
L3 |
| Quality of Service (QoS) support |
Y |
| Web-based management |
Y |
| ARP inspection |
Y |
| System event log |
Y |
| MIB support |
RFC 1213; RFC 4188; RFC 1157, 2571-2576; RFC 1907; RFC 1757, 2819; RFC 2021; RFC 1398, 1643, 1650, 2358, 2665; RFC 2674 802.1p 2233, 2863 IF MIB; RFC 2618; RFC 2620; RFC 2925; RFC 2674, 4363; RFC 1065, 1066, 1155, 1156, 2578; RFC 1215; RFC 1212; RFC 1215; RFC 1157, 2571-2576; RFC 4022; RFC 4113; RFC 4293; RFC 2737 |
| Ports & interfaces |
| Basic switching RJ-45 Ethernet ports quantity |
48 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| SFP+ module slots quantity |
4 |
| Fiber optic connector |
SFP+ |
| USB 2.0 ports quantity |
1 |
| Power connector |
AC-in jack |
| Network |
| Networking standards |
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3az, IEEE 802.3x |
| 10G support |
Y |
| Copper ethernet cabling technology |
10BASE-T, 10GBASE-T, 100BASE-TX, 1000BASE-T |
| Port mirroring |
Y |
| Flow control support |
Y |
| Link aggregation |
Y |
| Broadcast storm control |
Y |
| Spanning tree protocol |
Y |
| Head-of-line (HOL) blocking |
Y |
| VLAN support |
Y |
| Virtual LAN features |
Private VLAN, Voice VLAN, Tagged VLAN, MAC address-based VLAN, Port-based VLAN |
| Number of VLANs |
4000 |
| Data transmission |
| Switching capacity |
216 Gbit/s |
| Forwarding rate |
161 Mpps |
| MAC address table |
16384 entries |
| Number of queues |
8 |
| Jumbo frames support |
Y |
| Packet buffer memory |
4 MB |
| Security |
| DHCP features |
DHCP server, DHCP snooping, DHCP relay, DHCP client |
| Access Control List (ACL) |
Y |
| Access Control List (ACL) egress |
512 |
| Access Control List (ACL) ingress |
2048 |
| IGMP snooping |
Y |
| Security algorithms |
SNMP, SNMPv3, SSH-2, SSL/TLS |
| SSH/SSL support |
Y |
| Loop protection |
Y |
| BPDU filtering/protection |
Y |
| Authentication |
Guest VLAN, MAC-based authentication, Port-based authentication |
| Root protection |
Y |
| Password protection |
Y |
| DoS attack prevention |
Y |
| Queue scheduling algorithms |
SP, WRR+SP, Weighted Round Robin (WRR) |
| Multicast features |
| Multicast support |
Y |
| Multicast features |
Controllable multicast |
| Protocols |
| GARP VLAN Registration Protocol (GVRP) |
Y |
| Virtual Router Redundancy Protocol (VRRP) |
Y |
| Routing protocols |
RIP |
| Design |
| Rack mounting |
Y |
| Stackable |
Y |
| Product colour |
Black, Grey |
| LED indicators |
Y |
| Number of fans |
2 fan(s) |
| Safety |
CB, cUL, BSMI, CCC |
| Certification |
FCC A, CE A, VCCI A, IC, RCM, BSMI, CCC |
| Performance |
| Physical stacking (units) |
9 |
| Virtual stacking (units) |
32 |
| Noise level |
51.9 dB |
| Telnet |
Y |
| sFlow |
Y |
| Mean time between failures (MTBF) |
478258 h |
| Technical details |
| Shipping (inner) case height |
46 cm |
| Shipping (inner) case width |
19.8 cm |
| Shipping (inner) case length |
52.4 cm |
| Shipping (inner) case net weight |
9.66 kg |
| Products per shipping (inner) case |
2 pc(s) |
| Pallet gross weight (air) |
522.6 kg |
| Master (outer) cases per pallet (air) |
48 pc(s) |
| Products per pallet (air) |
96 pc(s) |
| Pallet gross length |
110 cm |
| Pallet gross width |
120 cm |
| Pallet height (air) |
197.5 cm |
| Pallet gross weight (sea) |
522.6 kg |
| Master (outer) cases per pallet (sea) |
48 pc(s) |
| Products per pallet (sea) |
96 pc(s) |
| Pallet height (sea) |
197.5 cm |
| Shipping (inner) case gross weight |
10.5 kg |
| Power |
| Redundant power supply (RPS) support |
Y |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Power consumption (max) |
50.62 W |
| Power over Ethernet (PoE) |
| Power over Ethernet (PoE) |
N |
| Operational conditions |
| Operating temperature (T-T) |
0 - 50 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
5 - 90% |
| Heat dissipation |
172.72 BTU/h |
| Weight & dimensions |
| Width |
440 mm |
| Depth |
290 mm |
| Height |
44 mm |
| Weight |
3.72 kg |
| Packaging data |
| Package width |
427 mm |
| Package depth |
506 mm |
| Package height |
70 mm |
| Package weight |
4.83 kg |
| Logistics data |
| Harmonized System (HS) code |
85176990 |
| Other features |
| I/O ports |
2 x 10GBASE-T |
